Sellstrom V845528009TB Tie Back Leading Edge SRL Class A

SKU:
SS-V845528009TB
UPC:
806808175045
MPN:
V845528009TB
Availability:
Ship 3-5 business days
Weight:
6.00 LBS
Width:
12.00 (in)
Height:
5.00 (in)
Depth:
12.00 (in)
Shipping:
Calculated at Checkout
MSRP: $663.46
$552.89
— You save $110.57
Frequently bought together:

Description

Features:

  • Tie-Back style features an all-in-one SRL and anchorage connector
  • Fall distance clearance is 2’ or less
  • 5,000 lbs snap hooks designed for Tie-Back applications
  • Lifeline is made with Dyneema material for the strongest fiber available
  • 310 lbs capacity (combined weight of person, tools, clothing, etc.)
  • Certified to the ANSI Z359.14 and CSA Z259.2.2 and Meets the latest OSHA regulations

Specifications:

Webbing ft (m) 0.77" (19 mm)
Length ft (m) 9 ft (2.7 m)
Capacity 310 lbs (136 kg) combined weight of person, tools, clothing, etc. One person use only.
Max Total Arrest Distance 24 in. (0.61 m)
Average arrest force 765 lbf (3,4 kN)
Storage Store in a cool dry place away from chemicals, water, corrosive environments, and sources of heat or spark
Operating Temperatures -22ºF to 122ºF (-30ºC to +50ºC)
Tie-Back application Approved for use as personal fall arrest and restraint.
Foot Level Tie Off Tested and approved for foot level tie off
Leading Edge Approved for use in vertical and horizontal applications
Housing Aluminum
Lifeline 0.77" (19 mm) Dyneema Webbing
Tie-Back 3’ abrasion-resistant jacket
Snaphook Zinc-plated steel, 5,000 lb. gate strength.
Harness Connector Steel

Sold/Each
